उत्पाद विवरण:
|
| Name: | Rail Cargo Open Top Wagon | Fixed Wheelbase: | 1574.8mm |
|---|---|---|---|
| Axle Load: | 20.5 T | Load Capacity: | 63 T |
| Max. Operation Speed: | 80km/h | Gauge: | 1067mm |
Rail Cargo Wagon Railway Covered Wagon
Description of Rail Cargo Covered Wagon:
Railway covered wagon (also known as covered goods wagon) is a type of rail freight car designed to transport goods that require protection from weather, theft, or damage. It is fully enclosed with rigid sides, a roof, and sliding or hinged doors for loading and unloading.
Main Characteristics of Rail Cargo Covered Wagon:
1) Structure:
Enclosed design with steel or aluminum body.
Typically has one or more large sliding doors (sometimes double doors).
Some models include ventilation systems for perishable goods.
2) Capacity:
Varies by region and design (e.g., European models: ~60–80 m³; North American boxcars: ~70–100 tons).
Length: Usually 12–18 meters (40–60 ft).
Parameters of Rail Covered Wagon:
| Gauge | 1000mm (can customize) |
| Distance between two coupler connecting wire | 26400mm |
| Length | 12323mm |
| Center distance of core plate | 7772mm |
| Max. Height(unloaded) | 3330mm |
| Max. Width | 2600mm |
| Fixed wheelbase | 1574.8mm |
| Diameter of wheel | customize |
| Height from track surface to coupler center line (unloaded) | 584m |
| Axle load | 12t |
| Tare weight | 19t |
| Load capacity | 33t |
| Volume capacity | 64m³ |
| Max. Operation speed | 80km/h |
| Min. Curve radius | 60m |
